Description
PARAMETERS
| Model | SCCM2024-II | SCCM3024-II | SCCM4524-II | SCCM4548-II | SCCM6048-II | SCCM8048-II | SCCM10048-II | SCCM12048-II |
| Maximum Battery Current | 20Amps | 30Amps | 45Amps | 45Amps | 60Amps | 80Amps | 100Amps | 120Amps |
| Nominal System Voltage | 12, 24V DC (Auto Detection) | 12V, 24V, 48V DC (Auto Detection) | ||||||
| Maximum Solar Input Voltage | 95V | 145V | 195V | |||||
| PV Start-up Voltage | 15V | |||||||
| PV Array MPPT Voltage Range | 12V DC/24V DC | 12V DC/24V DC/48V DC | ||||||
| 15-80V DC/30-80V DC | 15-130V DC/30-130V DC 60-130V DC |
15-170V DC/30-170V DC 60-170V DC |
||||||
| Maximum Input Power | 12V-280W | 12V-420W | 12V-625W | 12V-625W | 12V-825W | 12V-1100W | 12V-1375W | 12V-1650W |
| 24V-550W | 24V-830W | 24V-1250W | 24V-1250W | 24V-1650W | 24V-2200W | 24V-2750W | 24V-3300W | |
| / | / | / | 48V-2500W | 48V-3300W | 48V-4400W | 48V-5500W | 48V-6600W | |
| Charging Algorithm | 3-Steps | |||||||
| Charging Stages | Bulk, Absorption, Float | |||||||
| Temperature Compensation Coefficient | -5mV/℃/cell (25°Cref.) | |||||||
| Temperature Compensation Range | 0℃ to 50℃ | |||||||
| Transient Surge Protection | 4500 Watts/port | |||||||
| Protections | Solar High Voltage Disconnect Solar High Voltage Reconnect Battery High Voltage Disconnect Battery High Voltage Reconnect High Temperature Disconnect High Temperature Reconnect |
